EnterRef. | Weight | Price | C | Clamps | Keyways | D (Length) | P (Maximum jaws range) | Q | R (Base height) | S | T (Width) | X | y | AND | Flanges | P (Maximum mouth distance) | Yes | Sparepart | Accessories | Buy |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
30/100P | 10Kg | 954,80 € | 33,5 | 1251261 | 12 | 37 | 140 | 90 | 50 | 32 | 16 | 17 | 42 | 42 | 1251261 | 140 | 30 | ![]() | ||
30/125P | 13.5Kg | 1.030,50 € | 40 | 1251261 | 12 | 42 | 150 | 103 | 55 | 33 | 16 | 22 | 50 | 50 | 1251261 | 150 | 35 | ![]() | ||
30/150P | 25.1Kg | 1.430,80 € | 56 | 1501261 | 16 | 51 | 180 | 125 | 58 | 38 | 18 | 26 | 58 | 58 | 1501261 | 180 | 40 | ![]() | ||
30/200P | 44.4Kg | 1.892,40 € | 66 | 2001261 | 16 | 61 | 190 | 140 | 63 | 44 | 22 | 26 | 58 | 58 | 2001261 | 190 | 44 | ![]() |
